VT6361 #01B003
Loading Schematic
Repair Parts for the Kobalt model VT6361 Portable Single-Stage Oil-Bath Electric Air Compressor
Specifications
Pump specs:
Â
- Oil Capacity 8.5 oz
- Compressor Head Bolts torque specs: 175-225 IN / LBS
- Bearing Cap Bolts torque specs: 50-120 IN / LBS
- Flywheel Bolt torque specs: 225-250 IN / LBS
- If you are looking for FT / LBS then please use this formula: IN / LBS divided by 12 = FT / LBS
- The journal on the crankshaft is 1.76" and the biggest part of the rod is 1.89"
- If pump knocks, check the top of the rod to make sure it is not egged out by the wrist pin
Manuals
Click here to order and download the Owner's Manual
Extras
We have your Kobalt VT6361 parts here. Whether you need a pressure switch, check valve or a new pump, we have your parts. Kobalt VT6361 parts are easy to come by at Master Tool Repair. We have helpful sales team members that can assist you with your repair. We have accessories as well as compressor oil to keep your pump running like a top. We keep the most popular Kobalt VT6361 parts in stock and we can order most other parts in a matter of a few days. To make ordering easier, we have created the ability for you to order parts by simply enlarging the schematic and then using your mouse to hover over the actual part. You will see the part pop up and are able to order by simply choosing the quantity of parts that you need and adding them to your cart. Make sure to keep spare parts on hand so that your down time will be minimal. Replace your Air Filter and Oil every 3 to 4 months if used frequently. Use straight 30W compressor oil (20W below 34 deg). Drain your tank regularly to prevent rust, especially in humid climates. This unit was made by Campbell Hausfeld.
Video
-
Tank Outlet Bushing 1-1/2 x 1/2 O RING PLUG #01AADB
MAT - EDI
Price: $25.63Need the o-ring order part # ST070191AVPG150006AV-MATPrice: $25.63 -
Oil Dipstick w/Filter Breather Assembly Grey #01A8D8
MAT - EDI
Price: $25.37Old Part Numbers: VT041703AJ, VT041703AV Note: dipstick model for 'push in' type crankcase.VT041701AJ-MATPrice: $25.37 -
Price: $23.08 -
PLASTIC AIR FILTER W/ELEMENT Style 1 #01A8F4
MAT - EDI
Price: $23.02Old Part Numbers: ST073919AV, WL012000AV, WL012300AVFilter - All plastic, 1/2" MPT. Uses 04 element, 2" diameter. Order extra for a backup! Replace this often (especially in dusty environments) to keep your pump from damage.WL026100AV-MATPrice: $23.02 -
Price: $20.86 -
Price: $20.58 -
REGULATOR-KOBALT #01C005
MAT - EDI
Price: $16.55Adjustable air pressure knob assembly. (Gauge sold separately). ÂRE300900AV-MATPrice: $16.55 -
On Sale
CAMPBELL CHECK VALVE KIT Unloader Line Kit #01AC7F
MAT - EDI
Now: $14.95Was: $43.89Old Part Numbers: PS846234VM, MP513901AJMay need this too if converting from old style pump to new pump. Check valve is NOT included in kit. May need to order new check valve with 1/8" port on side in addition to this kit if your check valve does NOT...MP513901SJ-MATNow: $14.95Was: $43.89 -
Price: $14.22 -
Price: $14.11 -
Air Filter Element Only CHA #01AA99
MAT - EDI
Price: $13.47Element only for air filter assembly.Specifications2 5/8" OD, 1 5/16" ID & 1 5/16" HeightVH901800AV-MATPrice: $13.47 -
Price: $12.99
