WL505103 #01AF03
Loading Schematic
Repair Parts for the Campbell Hausfeld model WL505103 Portable Oil-Free Air Compressor
Extra Details
Click here to view where the pump model number is normally found
-
Pressure Switch Kit #01A936
MAT - EDI
Price: $106.59Old Part Numbers: CW207576AV100-125 PSICW210100SJ-MATPrice: $106.59 -
Bleeder Valve #048A8D
Hubbell
Price: $42.61Old Part Numbers: CW000800AV, 69DJA Replace if broken, but replace Check Valve if constantly leaking.HC69DJA-HUPrice: $42.61 -
CHECK VALVE ASSY 3/8T WL #01B149
MAT - EDI
Price: $37.29Old Part Numbers: CV217101AJ, CV221505AJCheck Valve, 3/8" comp x 1/2" MPT with hose barb fitting.CV221505SJ-MATPrice: $37.29 -
Price: $28.45 -
Price: $27.85 -
FAN KIT #01ABDB
MAT - EDI
Price: $22.70Old Part Numbers: WL209801AJKit includes # 10-12. Note: order this item for model WL362002AJ only.WL209801SJ-MATPrice: $22.70 -
ASME SAFETY VALVE 140 PSI 1/4 NPT #01ACAC
MAT - EDI
Price: $21.34Old Part Numbers: V-203600BLRating 140 PSI If your valve leaks below the pressure listed on the side of the valve, replace this vital safety feature. Used with WL650801.V-215100AV-MATPrice: $21.34 -
Price: $14.64 -
Price: $11.65 -
68-8-6X 1/2 OD X 3/8 MIP COMP ADPT NO LEAD #100B90
Southern Plumbing
Price: $10.80Old Part Numbers: 68-8-6135-40064-SPPrice: $10.80 -
Price: $9.88 -
Pressure Gauge 1.5 IN 300 PSI GAUGE 1/8 NPT LOW #01A8A6
MAT - EDI
Price: $9.63Old Part Numbers: GA016306AV GA016300AV, GA016310AV, GA016303AV, GA016308AV0-300 PSI, 1/8" NPT, LEFT MOUNT, 1.625" FACEGA016313AV-MATPrice: $9.63
